Hydraulic Breaker Hammer Chisel Suitable 22 26 ton Excavator
Model
| Model # | Design | Diameters (mm) |
Length (mm) |
Weight (kg) |
Interchangeable Model |
| Toku TNB-08E/1M |  |
45 | 470 | Teledyne TB100 | |
| Toku TNB-1E/2M |  |
50 | 500/600 | Drago DRH80, Teledyne TB120/125 | |
| Toku TNB-2E/3M |  |
58 | 650/700 | Drago DRH120, Teledyne TB180/225 | |
| Toku TNB-3E/4M |  |
64 | 650/700 | Drago DRH150, Teledyne TB275 | |
| Toku TNB-4E/5M |  |
75 | 650/720 | Drago DRH180, Teledyne TB220/325 | |
| Toku TNB-6E/7M |  |
95 | 760/850 | Drago DRH 280, Teledyne TB400/425/625 | |
| Toku TNB-7E/10E |  |
115 | 950/1000 | Drago DRH650S/900, Teledyne TB700/725/750/825 | |
| Toku TNB-14E/16E |  |
135 | 1150 | Drago DRH1150S/1600S, Teledyne TB900/925/975/1000/1025 | |
| Toku TNB-22E/23E |  |
146 | 1300 | Drago DRH1900, Teledyne TB1300/1425 | |
| Toku TNB-30E/31E |  |
160 | 1500 | Teledyne TB1825/2075 | |
| Toku TNB-100 |  |
115 | 1050 | Teledyne TB830 | |
| Toku TNB-150 |  |
135 | 1180/1270 | Teledyne TB 980 | |
| Toku TNB-190 |  |
1200 | |||
| Toku TNB-230 |  |
1220 | Teledyne TB1680 | ||
| Toku TNB-310 |  |
1350 | Teledyne TB 2080 | ||
| Toku TNB-400 |  |
1550 | Teledyne TB 2580 |
Main Specification
| Item | Hydraulic Breaker Hammer Chisel suitable 20 21 22 23 24 25 26 27ton excavator |
| Brand Name | DNG Chisel |
| Place of Origin | China |
| Chisels Materials | 40Cr, 42CrMo, 46A , 48A |
| Steel Type | Hot Rolled Steel |
| Chisel Type | Blunt,Wedge, Moil, Flat, Conical, etc. |
| Minimum Order Quantity | 10 pieces |
| Packaging Detail | Pallet or wooden box |
| Delivery time | 4-15 working days |
| Supply Ability | 300,000 pieces per year |
| Near Port | Qingdao Port |
Our TOKU hydraulic breaker chisels have a competitive price. Production technology, including heat treatment, allows us to produce hydraulic breaker chisels with an optimal combination of hardness and strength, excluding increased fragility. The correct quenching/tempering regime and the correct chemical composition of the steels used to make the wedge increase the resistance to fracture. If you purchase on an ongoing basis, we will give you special prices.
We can also supply other kinds of hydraulic breaker chisels according to your needs. Just tell us the modal name of your hydraulic breaker chisels, we will offer you what you need and try our best to meet your requirements.
In addition to superior performance, our products come with comprehensive after-sales service and warranty, giving you peace of mind and support long after your purchase. This commitment to customer satisfaction is a testament to our commitment to not only delivering top-notch products, but also to providing our customers with a positive overall experience.
