Blunt Wedge Diamond Point Jack Moil Rock Hydraulic Break Chisel
Model
| Model # | Design | Diameters (mm) |
Length (mm) |
Weight (kg) |
Interchangeable Model |
| Rammer S18/ Piccolo |  |
40 | 400 | 4 | Kubota KXB300/350, Volvo HB80 |
| Rammer S21 |  |
45 | 480/560 | 5/6 | Caterpillar H45FT, Bobcat 1750, Case CB140, JCB HM160, Kubota KXB400/BTB400, O&K H32, Volvo HB130 |
| Rammer S22 |  |
50 | 530/600 | 8/9 | Caterpillar H50FT, Case CB200, Kubota KXB450, O&K H45, Volvo HB200 |
| Rammer S23 |  |
63 | 680/780 | 15/17 | Caterpillar H63/H63FT, Case CB370, JCB HM260, Kubota KXB500, O&K H65, Volvo HB300 |
| Rammer S25 |  |
70 | 730/830 | 20/23 | Caterpillar H70/H70FT, Case CB620, JCB HM360, Kubota KXB600, O&K H85, Volvo HB440 |
| Rammer S26 |  |
90 | 850 | 35 | |
| Rammer S27 |  |
84 | 840 | 34 | Caterpillar H90/H90FT, Case CB735, JCB HM550, O&K H120, Volvo HB600 |
| Rammer S29 |  |
95 | 900 | 47 | Caterpillar H100/H100FT, Case CB1150, JCB HM850, O&K H150, Volvo HB800 |
| Rammer S52 |  |
110 | 900 | 55 | |
| Rammer S54 |  |
115 | 1050 | 80 | |
| Rammer S55/E66 |  |
115 | 1050/1150 | 80/88 | Caterpillar H120s, Case CB2850, JCB HM1350, O&K H260 |
| Rammer S56 |  |
130 | 1100 | 100 | |
| Rammer S82 |  |
140 | 1200 | 135 | |
| Rammer S83 |  |
140 | 1200 | 135 | Caterpillar H140As |
| Rammer S84 |  |
160 | 1350 | 195 | Caterpillar H160As |
| Rammer S86 |  |
169 | 1450 | 240 | |
| Rammer E63 |  |
115 | 1000 | 68 | JCB HM1150, Volvo HB1100 |
| Rammer E64 |  |
106 | 1050/1150 | 64/70 | Caterpillar H115s, Case CB1450, JCB HM1050, O&K H200 |
| Rammer E65 |  |
125 | 1050 | 80 | JCB HM1450, Volvo HB1400 |
| Rammer E66/S55 |  |
115 | 1050/1150 | 80/88 | Caterpillar H120s, Case CB2850, JCB HM1350, O&K H260 |
| Rammer E68 |  |
130 | 1100/1200 | 100/110 | Caterpillar H130s, Case CB3750, JCB HM1750, O&K H310, Volvo HB1700 |
| Rammer G80 |  |
140 | 1200 | 135 | Caterpillar H140Cs/140Ds, Case CB4000, JCB HM2350, O&K H380, Volvo HB2400 |
| Rammer G90 |  |
159 | 1400 | 205 | Caterpillar H160Cs/160Ds, Case CB5200, JCB HM2950, O&K H530, Volvo HB3200 |
| Rammer G100 |  |
169 | 1450 | 240 | Caterpillar H180s, JCB HM3850 |
| Rammer G110 |  |
174 | 1450 | 240 | Caterpillar H180Ds, JCB HM3950, O&K H700, Volvo HB3800 |
| Rammer G120 |  |
195 | 1500 | 325 | Caterpillar H195 |
| Rammer G130 |  |
203 | 1550 | 340 | |
| Rammer M14 |  |
125 | 1100 | 92 | |
| Rammer M18 |  |
140 | 1200 | 137 |
Main Specification
| Item | Blunt Wedge Diamond Point Jack Hammer Moil Rock Hydraulic Break Chisel |
| Brand Name | DNG Chisel |
| Place of Origin | China |
| Chisels Materials | 40Cr, 42CrMo, 46A , 48A |
| Steel Type | Hot Rolled Steel |
| Chisel Type | Blunt,Wedge, Moil, Flat, Conical, etc. |
| Minimum Order Quantity | 10 pieces |
| Packaging Detail | Pallet or wooden box |
| Delivery time | 4-15 working days |
| Supply Ability | 300,000 pieces per year |
| Near Port | Qingdao Port |
Rammer hammers are strong and durable, providing maximum production output while providing the most economical cost of ownership and operation.
And different chisels also have their own functions, just choose the right tool, you can use the hydraulic breakers totally and best. Our company can supply the optimal solution and produce what you need. Besides, one step shopping also can give your work and lift the most convenience.
